Waterproof Anti Noisy PVC Floor Tile Making Machine Ceiling Panel Extrusion Line

Place of Origin ZHANGJIAGANG,CHINA
Brand Name XPM
Certification CE,ISO
Model Number SRL-Z200/500
Minimum Order Quantity 1 SET
Price 90,000-120,000 USD/SET
Packaging Details WOODEN CASE PACKING AND PLASTIC FILM
Delivery Time 45 WORKING DAYS
Payment Terms T/T
Supply Ability 20 SETS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Contactor Brand Siemens Raw Material PVC,WPC
Color Customized Screw Conical Twin Screw
Warranty 1 Year Inverter ABB
Voltage 220V,380V Or Customized Application PVC Hollow Tile
Output 150-320Kg/H Motor Power 37Kw
High Light

waterproof floor tile making machine

,

Anti noisy floor tile making machine

,

42kw PVC ceiling panel extrusion line

Leave a Message
Product Description

PVC Floor Tile Production Line PVC Ceiling Panel Extrusion Making Machine Line


Advantage:
Anti-noisy,anti-erosion,heating resistance and water proof.
Features:
1.Optional to adopt conical twin screw extruder and parallel twin screw extruder.
2.Supply formula guide and staple raw material purchase
3.Professional analyzing and design by considering production cost and tiles' performance.
4.Single layer or A+B/A+B+C/A+B+A layers avaibable

Products Description
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 0

Extrusion Part

1. forced extruding
2. high quality
3.wide adaptability
4.long working life
5.low shearing speed
6.hard decomposition
7.good compounding& plasticization effect
8.direct shaping of powder material and etc.
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 1

Mould Part

Name: T-DIA or Ectrusion mould
1. Clothes hanger runner
2. Mirror polishing Cr plating
3. Three dimensional flow simulation software design
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 2

Embossing Roller

1. Up roller is Embossing roller, the down roller is mirror Roller. Roller surface treatment by hard chrome plated (depth 0.10-0.15)
2. Design of spiral flow passage in roller
3. Motor separately drive to ensure consistent speed
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 3

Forming Machine

Name: Corrugated Roof Tile Forming Machine
1.Haul off roller material: Neoprene CR
2.Rise and drop method of mould: pneumatic
3.Fine adjustment method: manual
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 4

Cutter

Technical Parameters:
1.Special positioning cevice to ensure the cutting accuracy
2.Cutting method for the saw blade cutting
3.The horizontal movement motor is 0.37kw
4.PLC HMI operation
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 5

Crusher

Technical Parameters:
1.The motor power is 11kw,15kw,22kw,30kw
2.Broken the amount of 200-600kg/h
3.Broken diameter 510*290
The main purpose:
Used for on-line production to produce edge scraps for recycling

Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 6


High Speed Mixer Unit

Name: High speed mixing unit
Technical parameters:
Model Capacity (kg/hr) Motor(kw)
SRL-Z200/500 350-450 30/42
SRL-Z300/600 550-650 40/55
SRL-Z500/1000 750-1000 55/75

Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 7

High Speed Mixing Unite

Name: High speed mixing unit
Technical parameters:
Model Capacity (kg/hr) Motor(kw)
SRL-Z200/500 350-450 30/42
SRL-Z300/600 550-650 40/55
SRL-Z500/1000 750-1000 55/75


No. Machine name Qty
1 Screw conveyor(with push device) 1pc
2 conical two screw extruder 1pc
3 Vacuum feeder for pellet 1pc
4 Drying hopper 1pc
5 single screw extruder 1pc
6 Extrusion mould 1pc
7 Distributor 1pc
8 Embossing roller 1pc
9 Forming machine with trimming device 1pc
10 Cutter 1pc
11 Stacket 1pc
12 Forming for ridger 1pc
13 Mould of top rodge,three way ridge,hip rodge,end of ridge 4pcs
14 Oven 1pc
15 Mixer unit 1pc
16 Screw conveyor for mixer unit 1pc


Product Application
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 8
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 9

Product Application

Machine name: Plastic PVC Composite Roof Tile Making machine
Finished product : Plastic roofing , PVC composite roofing , Plastic corrugated roofing

Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 10

Product features:

Using life more than 20years
Good sound and heat insulation
Fire resistance, anti-corrosion
Using recycled PVC ,environment-friendly
Excellent anti-load performance
Easy to install, packing and transport
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 11
Plants, steel factories, warehouse, farm market, market access, sheds and other high-end roofing materials. Especially in corrosive chemical plants, smelters, ceramic plants, soy sauce factory, chemical plant, printing and dyeing plant, organic solvent factory, acid, alkali and other corrosive plant.


Company Profile

Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 12
SAIJIA MACHINERY

Continously Innovating And Manufacuturing Of Plastic Machinery.ZHANGJIAGANG SAIJIA MACHINERY TECHNOLOGY CO.,LTD.Our main products are: plastic pipe extrusion line and plastic machine.The main products are popular exported to international market,including Russia,Australia, Southeast Asia,Middle East,East Europe.Africa and other countries.

ZHANGJIAGANG SAIJIA MACHINERY TECHNOLOGY CO.,LTD.
Zhangjiagang Saijia was established in 2000. The production experience is mature and rich. Among them, it has been exporting for more than 20 years, and more than 100 countries have exported. The annual export turnover is about 15 million US dollars. Our company's production base covers more than 50,000 square meters. , Modern office and production room more than 35,000 square meters, with experienced high-quality staff team, first-class equipment, perfect and effective quality assurance system, advanced and complete testing equipment.

Workshop
We know the quality is the life of our company. Our company insists to manufacture all machine units by ourselves in order to control quality strictly by our quality inspectors. To implement this concept, we have built our own tooling and CNC workshop. Even if some parts from our certified supplier, our quality inspector will check these parts before entering into our warehouse.
Waterproof Anti Noisy PVC Floor Tile Making Machine  Ceiling Panel Extrusion Line 13
Warmly welcome to visit our workshop, and sincerely hope we can have long term cooperation in near future!
