500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304

Brand Name XPM
Certification CE,ISO
Model Number SMF400/500/600/800
Minimum Order Quantity 1 SET
Price 7,000-15,000 USD/SET
Delivery Time 45 WORKING DAYS
Payment Terms T/T
Supply Ability 20 SETS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Contactor Brand Siemens Raw Material SUS304
Color Customized Warranty 1 Year
Voltage 380V 50Hz 3phases Application Pulverizer
Output 100 - 500 Kg/h Motor Power 30Kw
High Light

500kg/h Plastic PVC Powder Making Machine


50Hz Pulveirzer Powder Making Machine


micro powder grinding mil SUS304

Leave a Message
Product Description

Plastic PVC Pulveirzer Grinder Mill Powder Making Machine For Sale


Product Description

The disc grinding pulverizer machine of the SMF series are available with disc diameter from 300 to 800 mm. These plastic pulverizer machines are high speed, precision grinders for the processing of medium hard, impact resistant and friable materials. The material to be pulverized is introduced through the centre of a vertically fixed grinding disc which is mounted concentrically with an identical high speed rotating disc. Centrifugal force carries the material through the grinding area and the resulting powder is collected with a blower and cyclone system. Depending on the application the machines can be equipped with one piece grinding discs or grinding segments.

The plastic pulverizer machine is mainly composed of electric motor, disc type blade, feeding fan, vibrating sieve, dust removing system, etc.

According to the customer's needs, you can choose some accessories, such as converter, vacuum loader, screw loader, magnetic net, metal separator, chiller, pulse dust collector, metering and weighing packaging machine, etc



We supply the PVC PE PP mill machine , the model : SMP400 , SMP500 , SMF600 , SMF800 ,SMWP500 (this model is combined the crusher and mill machine together)

The production capacity 50-500kg/h

The main parameter as below :

1 Model   SMP-500
2 Inner diameter of crushing room mm Ф500
3 Motor power KW 55
4 Crushing capacity Kg/h 200-300
5 Main axes rotating speed r/min 3200
6 Cutter head. Qty/Dia.   1set/500mm
7 Blade Qty. Pcs 36
8 Blower motor power Kw 5.5
9 Vibrating screen motor power Kw 0.75
10 Vibrating frequency t/min 1440
11 Diameter of vibrating screen Mm 1000
12 Dimensions mm 1650X1500X1630
13 N.W kg 1700
14 Application   PVC,PE etc recycling mill

500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 0500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 1

500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 2


Main Features

1.XPM series pulverizer is disc-type blade pulverizer.The machine widely used for plastic and rubber industry.It is the ideal equipment to process heat plastic and suitable for PE PP PVC and other material.
2.The machine is special purpose equipment for plastic factory to reduce production costs and improve economic efficiency.
3.The main shaft bearing adopt Japanese original NSK brand,unique bearing dustproof device,can resist dust.

500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 3




Company Profile

500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 4


Continously Innovating And Manufacuturing Of Plastic Machinery.ZHANGJIAGANG SAIJIA MACHINERY TECHNOLOGY CO.,LTD.Our main products are: plastic pipe extrusion line and plastic machine.The main products are popular exported to international market,including Russia,Australia, Southeast Asia,Middle East,East Europe.Africa and other countries.



Zhangjiagang Saijia was established in 2000. The production experience is mature and rich. Among them, it has been exporting for more than 20 years, and more than 100 countries have exported. The annual export turnover is about 15 million US dollars. Our company's production base covers more than 50,000 square meters. , Modern office and production room more than 35,000 square meters, with experienced high-quality staff team, first-class equipment, perfect and effective quality assurance system, advanced and complete testing equipment.



We know the quality is the life of our company. Our company insists to manufacture all machine units by ourselves in order to control quality strictly by our quality inspectors. To implement this concept, we have built our own tooling and CNC workshop. Even if some parts from our certified supplier, our quality inspector will check these parts before entering into our warehouse.

500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 5
Warmly welcome to visit our workshop, and sincerely hope we can have long term cooperation in near future!


500kg/H 50Hz Plastic PVC Pulveirzer Micro Powder Making Machine Grinding Mill SUS304 6


1) Are we manufacture or trade company?
We are manufacture,have 20 years' experiences in this field.

2) What kind machines we produce?
Our factory produce plastic pipes machines, plastic machine.

3) What kind payment we accept?
Payment term like T/T

4) How long we need to produce the machines?
According to different machine model and configuation, we need different time, like 40 days to 2 months.

5) Will the machine be delivered on time ?
Sure,we will deliver your machine up recieving the balance payment.

6) How about the machine quality?
Our machine quality is reliable.We select every parts on the machine strictly and production and installation is done by
professional workers.We test each production step for the best machine.

7) How about the price?
You know ,the goods counts the the price.We select the best machine raw material such as siemens electrics,schneider and ABB etc.We will provide you the best machine with best price.

8) How long is your machine’s guarantee time?
One year

9) What can you provide for after sale service?
We can send engineers to your factory for installation and training.also 24 hours on-line service for you.
